Product Summary

The AD654JR is a monolithic V/F converter consisting of an input amplifier, a precision oscillator system, and a high current output stage.

Parametrics

Absolute maximum ratings: (1)Total Supply Voltage:36 V; (2)Maximum Input Voltage:–300 mV to +VS; (3)Maximum Output Current:Instantaneous:50 mA, Sustained:25 mA; (4)Logic Common to –VS:–500 mV to (+VS –4); (5)Storage Temperature Range:–65℃ to +150℃.

Features

Features: (1)Low Cost; (2)Single or Dual Supply, 5 V to 36 V, 65 V to 618 V; (3)Full-Scale Frequency Up to 500 kHz; (4)Minimum Number of External Components Needed; (5)Versatile Input Amplifier; (6)Positive or Negative Voltage Modes; (7)Negative Current Mode; (8)High Input Impedance, Low Drift; (9)Low Power: 2.0 mA Quiescent Current; (10)Low Offset: 1 mV.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
AD654JRZ-REEL7
AD654JRZ-REEL7

IC V-F CONVERTER MONO 8-SOIC TR
Data Sheet
0-750: $2.90
AD654JRZ-REEL
AD654JRZ-REEL

IC V-F CONVERTER MONO 8-SOIC TR
Data Sheet
0-2500: $2.71
AD654JRZ
AD654JRZ

IC V-F CONVERTER MONO 8-SOIC
Data Sheet
0-1: $5.08
1-10: $4.57
10-100: $3.76
100-250: $3.45
250-500: $3.15
500-1000: $2.74
1000-2500: $2.71
AD654JR-REEL7
AD654JR-REEL7

IC V-F CONVERTER MONO 8-SOIC
Data Sheet
0-750: $3.36
AD654JR-REEL
AD654JR-REEL

IC V-F CONV MONO 500KHZ 8-SOIC
Data Sheet
0-2500: $3.13
AD654JR
AD654JR

IC V-F CONVERTER MONO 8-SOIC
Data Sheet
0-98: $4.82
