Product Summary

The RS-15-5 is a 15W Single Output Switching Power Supply.

Parametrics

RS-15-5 absolute maximum ratings: (1)Output DC voltage: 5 V; (2)Output rated current: 3 A; (3)Output current range: 0 A to 3 A; (4)Output rated power: 15 W; (5)Output voltage ADJ. range: 4.75 V to 5.5 V.

Features

RS-15-5 features: (1)Universal AC input / Full range; (2)Protections: Short circuit / Overload / Over voltage / Over temperature; (3)Cooling by free air convection; (4)LED indicator for power on; (5)100% full load burn-in test; (6)Withstand 300VAC surge input for 5 second; (7)High operating temperature up to 70; (8)Withstand 5G vibration test; (9)High efficiency, long life and high reliability; (10)3 years warranty.

Diagrams

RS-15-5 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
RS-15-5
RS-15-5
Mean Well
Linear and Switching Power Supplies 15W 5V 3A
Data Sheet
0-1: $15.23
1-10: $13.70
10-20: $11.76
20-50: $10.88
Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
RS-100
RS-100
Mean Well
Linear and Switching Power Supplies
Data Sheet
Negotiable
RS-100-12
RS-100-12
Mean Well
Linear and Switching Power Supplies 102W 12V 8.5A
Data Sheet
0-1: $40.09
1-10: $34.45
10-20: $32.77
20-50: $31.00
RS-100-15
RS-100-15
Mean Well
Linear and Switching Power Supplies 105W 15V 7A
Data Sheet
0-1: $40.09
1-10: $34.45
10-20: $32.77
20-50: $31.00
RS-100-3.3
RS-100-3.3
Mean Well
Linear and Switching Power Supplies 66W 3.3V 20A
Data Sheet
0-1: $40.09
1-10: $34.45
10-20: $32.77
20-50: $31.00
RS-100-48
RS-100-48
Mean Well
Linear and Switching Power Supplies 110.4W 48V 2.3A
Data Sheet
0-1: $40.09
1-10: $34.45
10-20: $32.77
20-50: $31.00
RS-100-5
RS-100-5
Mean Well
Linear and Switching Power Supplies 80W 5V 16A
Data Sheet
0-1: $38.40
1-10: $33.00
10-20: $31.39
20-50: $29.70
